What is the Fastest Way to Write to Sqlite from Java in 2023?

Background

Our challenge was to insert data into a sqlite database as quickly as possible. You can find a lot of information on insert performance on the internet. Most information is already a couple of years old. Sqlite has improved. The drivers have improved. Java has improved.

A lot of information we found was no longer accurate or was slower than not tuning anything at all.

We therefore benchmarked the insert performance ourselves. Our findings are a bit surprising and are different to what is currently recommended on e.g. Stack Overflow (https://stackoverflow.com/questions/1711631/improve-insert-per-second-performance-of-sqlite).

Setup

Artificial data. 5 columns with text should be inserted 5 million times.
We ran the benchmark on a Mac M1 Laptop.
Result is a sqlite database with 160MB.
sqlite-jdbc-3.41.0.1.
Java OpenJDK 19.

You can find the code at https://github.com/raphaelbauer/java-sqlite-insert-benchmark . Simply check out the repository and run the file BenchmarkOptionsToInsertIntoSqlite.java. All code is in that one file.

Limits

That’s not a real benchmark like JMH. But as rule of thumb it should work fine.
You might get different results with different OSses and filesystems.

Conclusion

Use one large transaction.
Statements are a bit faster than prepared statements - but for all practical purposes you should use prepared statements to omit SQL injections.
Configuration of SQLite (synchronization mode, memory and such) did not bring any measurable benefit.
Batching did NOT bring any benefit.

Results and insert performance

No transaction was 1000 times slower than a single transaction.
A simple statement in one big transaction can write 833_333 rows per second on my machine.
A prepared statement in one big transaction can write 714_285 rows per second on my machine.
A prepared statement in one big transaction with batches of 1000 can write 500_000 rows per second on my machine.

Some notes:

It is surprising that batching is slower than not batching. We tried different batch sizes (1000, 10000, 100000) - it does not change much.
We tried many PRAGMA configurations on sqlite level. We could not find any big difference using any of the PRAGMA configs.

Questions

Question: What is the fastest way to write to a SQLite database?

Simple statements, one transaction, no batches.
For practical reasons - because you don’t want to have SQL injections - you should use simple prepared statements, one transaction, no batches.

Question: Do SQlite configuration options give you any edge?

In short: No.

We tried different variations of the following:

SQLiteConfig config = new SQLiteConfig();
config.setJournalMode(SQLiteConfig.JournalMode.OFF);
config.setSynchronous(SQLiteConfig.SynchronousMode.OFF);
config.setLockingMode(SQLiteConfig.LockingMode.EXCLUSIVE);
config.setTempStore(SQLiteConfig.TempStore.MEMORY);
config.setPragma(SQLiteConfig.Pragma.MMAP_SIZE, "30000000000");

It did not change anything significantly in terms of write performance.

Question: Can’t we just parallelize the work?

Nope. An insert will lock the table. You can only use one connection to write to the database at a given times. Multiple write efforts will block each other.

Question: What has the most impact on performance?

Using one transaction.

Do all insert commands within one huge transaction. Not using a transaction is 1000x slower than the other way round. Absolutely use something like connection.setAutocommit(false) - and then connection.commit() at the end.
